terminal block DL166-XX-5.0

Name: terminal block DL166XX50
Brand: DELI
Price: 1 USD

China terminal block DL166-XX-5.0 wholesale

Brand Name : DELI

Model Number : DL166-XX-5.0

Place of Origin : CN

MOQ : 100

Payment Terms : T/T, Western Union

Supply Ability : 10000

Delivery Time : 2DAYS

Packaging Details : BAG

Pitch : 5.0MM

Poles : 2P-24P

Screw : M3、Steel、Zinc plated

Housing : PA66. UL94V-0

Rated voltage : 250V/300V

Rated current : 22A/16A

Withstanding voltage : AC2000V/1Min

Wire range : 18-12AWG

Contact Now

MATERIAL

Pitch:5.0MM

Poles: 2P-24P

Screw:M3,Steel,Zinc plated

Wire guard:

phosphor bronze,

Ni plateor stainless steel

Pin header:Brass, Tin plated

Housing:PA66. UL94V-0

ELECTRICAL

Rated voltage:250V/300V

Rated current:22A/16A

Withstanding voltage:AC2000V/1Min

Wire range:18-12AWG

MECHANICAL

Temperature range:-40℃-- +105℃

MAX soldering:+250℃ for 5 sec

Torque:0.5Nm(4.4 lb.in)

Strip length:6-7mm

DeLi Electronics Technology Co., Ltd

PART# : DL166-XX-5.0
