DL127SF-XX-5.08mm Pcb Wire Connector , 2 Pins Screw Down Terminal Block 2-24P

Name: DL127SFXX508mm Pcb Wire Connector 2 Pins Screw Down Terminal Block 224P
Brand: DELI
Price: 1 USD

China DL127SF-XX-5.08mm Pcb Wire Connector , 2 Pins Screw Down Terminal Block 2-24P wholesale

Brand Name : DELI

Model Number : DL127SF-XX-5.08

Place of Origin : CN

MOQ : 100

Payment Terms : T/T, Western Union

Supply Ability : 10000

Delivery Time : 2DAYS

Packaging Details : BAG

Pitch : 5.08 MM

Poles : 2-24P

Screw : M2.5、Steel、 Zinc plated

Housing : PA66. UL94V-0

Rated voltage : 300V

Rated current : 10A

Withstanding voltage : AC2000V/1Min

Wire range : 26-16AWG

Contact Now

MATERIAL

Pitch:5.08 MM

Poles: 2-24P

Screw:M2.5,Steel,Zinc plated

Wire cage: Brass, Ni plated

Pin header:Brass, Tin plated

Housing:PA66. UL94V-0

ELECTRICAL

Rated voltage:300V

Rated current:10A

Withstanding voltage:AC2000V/1Min

Wire range:26-16AWG

MECHANICAL

Temperature range:-40℃-- +105℃

MAX soldering:+250℃ for 5 sec

Torque:0.4Nm(3.5 lb.in)

Strip length:7mm

DL127SF-XX-5.08mm Pcb Wire Connector , 2 Pins Screw Down Terminal Block 2-24P

DeLi Electronics Technology Co., Ltd

PART# : DL127SF-XX-5.08

Product Tags:

wire to board connector

terminal block connector

DL127SF-XX-5.08mm Pcb Wire Connector , 2 Pins Screw Down Terminal Block 2-24P Images
